100W Constant Voltage, Slimline LED Driver, 12v, IP67
Commercial Grade LED Signage Driver
Full Specification
| Product Code | SL-100-12-IP |
| Wattage | 100W |
| Voltage (DC) | 12v |
| Current (DC) | 8.33A |
| Length | 192mm |
| Width | 41mm |
| Depth | 27mm |
| Dimmable | No |
| IP Rating | IP67 |
| Input Voltage | 175 / 265 AC |
| Input Current | 1A / 230V |
| Inrush Current | 40A / 230V |
| Input Frequency | 50 / 60Hz |
| Power Factor | >0.9 |
| Weight | 410g |
| Operating Temp | -20°C / 50°C |
| Warranty | 3 Years |
100W Slimline LED Driver – 12V Constant Voltage, IP67 Rated
The 100W constant voltage LED driver is a high-performance power supply designed for professional signage and commercial lighting projects. Delivering a reliable 12V DC output at up to 8.33A, it provides consistent power for larger LED installations that demand stability and long-term durability.
Built with a slimline profile measuring 192mm x 41mm x 27mm and weighing 410g, this driver is compact yet robust, making it easy to fit into restricted spaces without compromising safety or efficiency.
With its IP67 rating, the driver is fully protected against dust and water ingress, making it a dependable choice for both indoor and outdoor applications. Operating in environments from -20°C to +50°C, it ensures reliable performance across a wide temperature range.
Featuring an input range of 175–265V AC, a low input current of 1A at 230V, and a power factor above 0.9, it is energy-efficient and stable. The 40A inrush current capacity safeguards your system during start-up, reducing risk of damage from sudden surges.
This driver is non-dimmable, ideal for signage and display lighting where flicker-free, consistent illumination is essential. Supported by a 3-year warranty, it’s a trusted solution for demanding commercial applications.
