35W Constant Voltage, Slimline LED Driver, 12v, IP67
Commercial Grade Signage LED Driver
Full Specification
| Product Code | SL-035-12-IP |
| Wattage | 35W |
| Voltage (DC) | 12v |
| Current (DC) | 2.9A |
| Length | 127mm |
| Width | 22mm |
| Depth | 27mm |
| Dimmable | Non Dimmable |
| IP Rating | IP67 |
| Input Voltage | 175 / 265 AC |
| Input Current | 0.3A / 230V |
| Inrush Current | 40A / 230V |
| Input Frequency | 50 / 60Hz |
| Power Factor | >0.9 |
| Weight | 190g |
| Operating Temp | -20°C / 50°C |
| Warranty | 3 Years |
35W Slimline LED Driver – 12V Constant Voltage, IP67 Rated
Designed for reliability in demanding commercial signage projects, this 35W constant voltage LED driver delivers consistent 12V output with a maximum load of 2.9A. Built in a slimline housing (127mm x 22mm x 27mm) and weighing just 190g, it’s compact enough to fit neatly into tight installations without compromising performance.
Engineered with an IP67 rating, the driver is fully protected against dust and water ingress, making it suitable for both indoor and outdoor use. It operates safely in temperatures from -20°C to +50°C, ensuring reliable performance in all weather conditions.
With an input voltage range of 175–265V AC, a high power factor of >0.9, and a low input current of 0.3A at 230V, this driver is both efficient and stable. It also features a 40A inrush current capacity, giving you confidence in its durability during start-up.
This unit is non-dimmable, making it ideal for straightforward signage applications where consistent, flicker-free illumination is essential. Backed by a 3-year warranty, the 35W Slimline LED Driver is a dependable choice for commercial LED signage and architectural lighting.
Upgrade your projects with a driver built for performance, efficiency, and long-term reliability.
