Ultraviolet LED Strip Light
Commercial Grade LED Strip Light
Full Specification
| Product Code | UV-12 / IP |
| Watts / M | 12W |
| Voltage | 24V |
| Led / M | 60 |
| Cut Points | 100mm |
| Strip Width | 8mm (IP: 8.5mm) |
| Lumens / M | 400-410 NM |
| Lumens / Watt | 120 |
| Colour Options | 400-410 NM |
| Cri | 90+ |
| Ip Rating | 20, 65, 67 |
| Beam Angle | 120° |
| Reel Length | 5m |
| Max Run Length | 5m (Power One End) |
| Warranty | 5 Years |
| Backing Tape | 3m 300LSE |
| Chip Set | Epistar (2835) |
Drawing around 12 watts per metre, INSTYLE’s UV LED strip lights are a reliable, high-quality choice for your linear ultra violet (black light) installations. Black light applications include bar and nightclub illumination, bedrooms, vehicles, game rooms, reprography, and murals/posters.
With 60 LEDs mounted on each metre of printed circuit board (PCB), our UV LED tapes are manufactured using the same Epistar-branded 2835 SMDs as our 12-watt white LED tapes. They also use the same extremely flexible 8mm PCBs, which provide excellent heat dispersal.
Outputting a wavelength in the range 400-410 nm, our UV LED tape is available in waterproof versions only (IP65- or IP67-rated) – which not only protect against moisture but also makes cleaning easier. Tape cut points are every 100mm, and we offer a cutting and soldering service – so we’ll make up your order to the exact lengths your project needs, no matter what size.
INSTYLE LED supplies commercial grade LED Tape using premium components, built to last, and we offer a variety of ways to dim this LED tape, from wireless to DMX to TRIAC to 0-10v, and more.
- Choose from IP65 splashproof & IP67 waterproof
- High grade, long lasting resistors to stop LED chip damage
- High Quality Branded UV (black light) LED chips
- Ideal for replacing UV fluorescent tubes.
- Premium white coating for protection of the PCB board and to stop short circuiting
- Wavelength 400-410 nm
- Commercial Grade LED Tape
